AL301XL Fusion Power Chair and Scooter

by Harmar (Model No. AL301XL)
With front and rear adjustable wheel cradles this platform can accommodate mobility products with up to a 48" wheelbase.
$2,119.00
List Price: $2,815.00
Our low price includes:
  • Free Shipping for Orders over $50
  • "Best on the Web" Return Policy
  • No Sales Tax
  • License Plate Mount
  • Manual Crank Back-Up
  • Hardwire Kit
  • 3 Year Limited Warranty
Shipping Information  Details »
Leaves Warehouse In:   7-10 Business Days   Details
Ground Shipping: FREE for orders over $50!
Expedited Shipping:        Go

2nd Day: $249.99          Overnight: $299.99
Expedited Shipping:       Unavailable
Overview

Features

  • FREE Heavy Duty Mobility Cover!
  • Accommodates large powerchairs and scooters
  • Self-tensioning retractors
  • Fully Powered
  • Oversized Aluminum Deck
  • Works with Class III Hitch

Key Specs

  • Works With Hitch Size:
    • Class III Hitch
  • Weight capacity: 350 lbs.
  • Weight: 124 lbs.
  • View All Specs

Manuals, Literature & Videos for the AL301XL Fusion Power Chair and Scooter

Overview of the AL301XL Fusion Power Chair and Scooter

The AL301XL is a fully powered lift that rises and lowers with the flip of a switch. This lift will work with large powerchairs and scooters, due to its oversized aluminum deck. The self-tensioning retractors atttach to your powerchair or scooter with no need for modifications or drilling, this makes it easy to secure your mobility device to the lift. The AL301XL is a great choice for larger power wheelchairs and scooters with a wheelbase up to 48”.

* Your Harmar warranty does not cover installation done by someone other than Harmar certified installations unless a battery pack is purchased.

More Information on the AL301XL Fusion Power Chair and Scooter

+ Details & Specs

Specifications for the AL301XL Fusion Power Chair and Scooter

Hitch Height:    5" to 19"
Power Source:    Battery
Hardwired
Works With Hitch Size:    Class III Hitch
Professional Install Available:    No
Service Contract Available:    No
Operation:    Power
Lifting Capacity:    350 lbs.
Recommended For:    Travel Scooters
Full Sized Scooters
Power Wheelchairs
Platform Size - Length:    39-53 in.
Platform Size - Width:    36 in.
Installed Product Weight:    100 lbs.
Type of Lift:    Outside Lift
Warranty:    3 Year Limited Warranty
Warranty - Transferable Warranty:    Yes

Approximate Shipping Dimensions and Weights

Product Weight: 124 lbs.
Box 1
Shipping Weight: 180.00 lbs.
Length: 42.00"
Width: 41.00"
Height: 13.00"

More Information on the AL301XL Fusion Power Chair and Scooter

+ Reviews

AL301XL Fusion Power Chair and Scooter Reviews

100% of reviewers recommend this!
Features
(4.3)
Quality
(4.3)
Ease of Use
(3.7)
Meets Expectations
(3.8)

These reviews are from SpinLife customers who have purchased and used the AL301XL Fusion Power Chair and Scooter.

Customer Reviews
Showing:

Overall

4.0/ 5
Features

4
Quality

4
Ease of Use

1
Meets Expectations

2
Great product with limitations
Reviewer: d. from granbury, tx

End User Desc: This product is used by a 66 year old male with back and leg issues.

Strengths: Built to last for a long, long time.

Weaknesses: Not a product for self-installation unless you have complete mobility and are willing to crawl around under your vehicle. Not a product that you would install to use and then remove when you did not need it. Its extremely heavy and in the case of a pickup truck where its common for the rear of the vehicle to be somewhat higher than the front it can be an absolute nightmare to attach it to the trailer hitch due to the weight. If your physically capable of dealing with 200+lbs of dead weight or if you are going to install it and leave it attached to your vehicle full time, then this is a great product.

Reviewed on 07/11/2015

Back to top

Overall

5.0/ 5
Features

5
Quality

5
Ease of Use

5
Meets Expectations

5
Reviewer: p. from canway, ar

End User Desc: This is a lift. We had the lift attached to a cubtruck. It is working out very well. Great product. I appreciate all of the information.

Strengths:

Weaknesses:

Reviewed on 09/10/2014

Back to top

Overall

5.0/ 5
Features

5
Quality

5
Ease of Use

5
Meets Expectations

5
Haven't had the scooter long enough.
Reviewer: s. from redding, ca

End User Desc: Lets just say I'm broken.

Strengths: Easy to install.

Weaknesses: At this time cant find any problems. Wait a little while???

Reviewed on 04/21/2014

Back to top

Overall

4.0/ 5
Features

4
Quality

4
Ease of Use

3
Meets Expectations

3
Straps keep coming loose.
Reviewer: d. from east alton, il

End User Desc: 59 years old. Pain in both knees. I drive a Prowler 3410 4 wheeled scooter.

Strengths: I left the wiring to the pros but it was easy to install. I highly recommend the swing away option. It handles my heavy duty scooter with no problems.

Weaknesses: The straps are a bad idea. My knees are bad and it's hard for me to bend down to hook it up to the seat even when it's fully raised. The bar under the seat keeps needing readjusting. The straps keep coming loose. I've seen other lifts with a special hold down option for the floor of the scooter. I wish it had this or a bar that holds it in place by the seat.

Reviewed on 07/21/2012

Back to top

Overall

3.0/ 5
Features

3
Quality

3
Ease of Use

3
Meets Expectations

3
Reviewer: e. from murfreesboro, tn (caregiver)

End User Desc:

Strengths: EASY USE

Weaknesses: ONLY ONE BOLT, WHICH IS A GRADE FIVE CAP SCREW SUPPORTING THE WHOLE WEIGHT OF THE LIFT AND THE CHAIR. SEEMS LIKE IT SHOULD HAVE A BETTER BOLT FOR THIS. ALSO WHEN THE CHAIR IS ON THE LIFT, THE LICENSE PLATE CAN NOT BE SEEN. THE TOWER IS NOT HIGH ENOUGH! NEED A BRACKET TO KEEP IT UP EVEN HIGHER.

Reviewed on 10/14/2009

Back to top

Overall

5.0/ 5
Features

5
Quality

5
Ease of Use

5
Meets Expectations

5
It is great i can go places i coujldn't go.
Reviewer: m. from saint meinrad, in

End User Desc:

Strengths: it is very good.

Weaknesses: none

Reviewed on 08/31/2007

Back to top

View All Reviews

More Information on the AL301XL Fusion Power Chair and Scooter

+ Warranty

Warranty Information for the AL301XL Fusion Power Chair and Scooter

Harmar Mobility warrants its vehicle lift and access ramp products against defects in material, mechanical and electrical components (parts), excluding labor cost, batteries and paint, for a period of three (3) years, provided that the products have been installed, maintained and operated properly. This warranty does not cover defects in vehicles on which Harmar Mobility products are installed or defects in Harmar Mobility products caused by defects in any part of the vehicle upon which the product is installed.


This warranty starts on the date of the retail purchase, provided the warranty certificate is returned to Harmar Mobility, completely and property filled out within ten (10) days of purchase. This warranty does not cover maintenance or adjustments. Harmar Mobility will not be charged for labor, consequential damage or repair expenses. Harmar Mobility will not, under any circumstances, be liable for the loss of the use of its products or the vehicles on which they are installed or loss of time. This warranty does not cover installation done by someone other than Harmar certified installations unless a battery pack is purchased.

This warranty becomes null and void if the product has been lost, damaged by accident, misused and/or neglected, or if the product has been modified in any way. Defective parts must be returned, prepaid, to Harmar Mobility for inspection prior to credit or replacement. At Harmar Mobility’s option, any part found to have been modified, over-stressed, damaged by accident, or misused is not covered by this warranty.


THIS WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES OR CONDITIONS, INCLUDING ALL IMPLIED WARRANTIES OR MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, AND THERE ARE NO WARRANTIES THAT EXTEND BEYOND THE DESCRIPTION OF THE LIMITED WARRANTY DESCRIBED HEREIN.

More Information on the AL301XL Fusion Power Chair and Scooter

+ Returns

SpinLife Return Policy for the AL301XL Fusion Power Chair and Scooter

This item is covered by the SpinLife "Best on the Web" 30-Day Return Policy with a required Restocking Fee.

As stated in the full Return Policy, this item may be returned within 30 days of receipt for a refund as long as the following conditions are met:

  • The item must be returned at the customer's expense in the original packaging.
  • The item must be in new condition--no cracks, scratches or dirty tires.
  • A Return Authorization must be requested from SpinLife within 30 days of delivery.
  • Once the Return Authorization has been received from SpinLife, the product must be returned within 14 days to receive a refund.
  • A 15% Restocking Fee is required to return this item.
